Dynamic positioning
Dynamic positioning (DP) is a computer-controlled system to automatically maintain a vessel's position and heading by using its own propellers and thrusters. Position reference sensors, combined with wind sensors, motion sensors andgyrocompasses, provide information to the computer pertaining to the vessel's position and the magnitude and direction of environmental forces affecting its position. Examples of vessel types that employ DP include, but are not limited to, ships andsemi-submersible mobile offshore drilling units (MODU), oceanographic research vessels and cruise ships.
The computer program contains a mathematical model of the vessel that includes information pertaining to the wind and current drag of the vessel and the location of the thrusters. This knowledge, combined with the sensor information, allows the computer to calculate the required steering angle and thruster output for each thruster. This allows operations at sea where mooring or anchoring is not feasible due to deep water, congestion on the sea bottom (pipelines, templates) or other problems.
Dynamic positioning may either be absolute in that the position is locked to a fixed point over the bottom, or relative to a moving object like another ship or an underwater vehicle. One may also position the ship at a favorable angle towards wind, waves and current, called weathervaning.
Dynamic positioning is used by much of the offshore oil industry, for example in the North Sea, Persian Gulf, Gulf of Mexico,West Africa, and off the coast of Brazil. There are currently more than 1800 DP ships.
Factory
Dynamic positioning started in the 1960s for offshore drilling. With drilling moving into ever deeper waters, Jack-up barges could not be used any more and anchoring became less economical.
In 1961 the drillship Cuss 1 was fitted with four steerable propellers, in an attempt to drill the first Moho well. It was possible to keep the ship in position above the well off La Jolla, California, at a depth of 948 meters.
After this, off the coast of Guadalupe, Mexico, five holes were drilled, the deepest at 183 m (601 ft) below the sea floor in 3,500 m (11,700 ft) of water, while maintaining a position within a radius of 180 meters. The ship's position was determined by radar ranging to buoys and sonar ranging from subsea beacons.
Whereas the Cuss 1 was kept in position manually, later in the same year Shell launched the drilling ship Eureka that had an analogue control system interfaced with a taut wire, making it the first true DP ship.[2]
While the first DP ships had analogue controllers and lacked redundancy, since then vast improvements have been made. Besides that, DP nowadays is not only used in the oil industry, but also on various other types of ships. In addition, DP is not limited to maintaining a fixed position any more. One of the possibilities is sailing an exact track, useful forcablelay, pipelay, survey and other tasks.
Comparison between position-keeping options
Other methods of position-keeping are the use of an anchor spread and the use of a jack-up barge. All have their own advantages and disadvantages.
| Comparison position-keeping options | ||
|---|---|---|
| Jack-up barge | Anchoring | Dynamic positioning |
Advantages:
| Advantages:
| Advantages:
|
Disadvantages:
| Disadvantages:
| Disadvantages:
|
Although all methods have their own advantages, dynamic positioning has made many operations possible that were not feasible before.
The costs are falling due to newer and cheaper technologies, and the advantages are becoming more compelling as offshore work enters ever deeper water and the environment (coral) is given more respect. With container operations, crowded ports can be made more efficient by quicker and more accurate berthing techniques. Cruise ship operations benefit from faster berthing and non-anchored "moorings" off beaches or inaccessible ports.
Applications
Important applications include:
- Servicing Aids to Navigation (ATON)
- Cable-laying
- Crane vessels
- Cruise ships
- Diving support vessels
- Dredging
- Drillships
- FPSOs
- Flotels
- Landing platform docks
- Maritime research
- Mine sweepers
- Pipe-laying ship
- Platform supply vessels
- Rockdumping
- Sea Launch
- Sea-based X-band radar
- Shuttle tankers
- Survey ships
Scope
A ship can be considered to have six degrees of freedom in its motion, i.e., it can move in any of six axes.
Three of these involve translation:
- surge (forward/astern)
- sway (starboard/port)
- heave (up/down)
and the other three rotation:
- roll (rotation about surge axis)
- pitch (rotation about sway axis)
- yaw (rotation about heave axis)
Dynamic positioning is concerned primarily with control of the ship in the horizontal plane, i.e., the three axes: surge, sway and yaw.
Requirements
A ship that is to be used for DP requires:
- to maintain position and heading, first of all the position and heading need to be known.
- a control computer to calculate the required control actions to maintain position and correct for position errors.
- thrust elements to apply forces to the ship as demanded by the control system.
For most applications, the position reference systems and thrust elements must be carefully considered when designing a DP ship. In particular, for good control of position in adverse weather, the thrust capability of the ship in three axes must be adequate.
Reference systems
Position reference systems
There are several means to determine a ship's position at sea. Most traditional methods used for ships navigation are not accurate enough for some modern requirements. For that reason, several positioning systems have been developed during the past decades. Producers of DP systems are: Kongsberg Maritime, Navis Engineering Oy, GE, DCNS, L3, MT-div.Chouest, Rolls-Royce plc, Praxis Automation Technology, . The applications and availability depends on the type of work and water depth. The most common Position reference/Measuring systems /Equipment (PRS/PME) are:
- DGPS, Differential GPS. The position obtained by GPS is not accurate enough for use by DP. The position is improved by use of a fixed ground-based reference station (differential station) that compares the GPS position to the known position of the station. The correction is sent to the DGPS receiver by long wave radio frequency. For use in DP an even higher accuracy and reliability is needed. Companies such as Veripos, Fugro or C&C Technologies supply differential signals via satellite, enabling the combination of several differential stations. The advantage of DGPS is that it is almost always available. Disadvantages include degradation of the signal by ionospheric or atmospheric disturbances, blockage of satellites by cranes or structures and deterioration of the signal at high altitudes.[3] There are also systems installed on vessels that use various Augmentation systems, as well as combining GPS position with GLONASS.[4]
- Acoustics. This system consists of one or more transponders placed on the seabed and a transducer placed in the ship's hull. The transducer sends an acoustic signal (by means of piezoelectric elements) to the transponder, which is triggered to reply. As the velocity of sound through water is known (preferably a soundprofile is taken regularly), the distance is known. Because there are many elements on the transducer, the direction of the signal from the transponder can be determined. Now the position of the ship relative to the transponder can be calculated. Disadvantages are the vulnerability to noise by thrusters or other acoustic systems. The use is limited in shallow waters because of ray bending that occurs when sound travels through water horizontally. Three types of HPR systems are commonly used:
- Ultra- or super- short base line, USBL or SSBL. This works as described above. Because the angle to the transponder is measured, a correction needs to be made for the ship's roll and pitch. These are determined by Motion Reference Units. Because of the nature of angle measurement, the accuracy deteriorates with increasing water depth.
- Long base line, LBL. This consists of an array of at least three transponders. The initial position of the transponders is determined by USBL and/ or by measuring the baselines between the transponders. Once that is done, only the ranges to the transponders need to be measured to determine a relative position. The position should theoretically be located at the intersection of imaginary spheres, one around each transponder, with a radius equal to the time between transmission and reception multiplied by the speed of sound through water. Because angle measurement is not necessary, the accuracy in large water depths is better than USBL.
- Short baseline, SBL. This works with an array of transducers in the ship's hull. These determine their position to a transponder, so a solution is found in the same way as with LBL. As the array is located on the ship, it needs to be corrected for roll and pitch.[5]
- Riser Angle Monitoring. On drillships, riser angle monitoring can be fed into the DP system. It may be an electrical inclinometer or based on USBL, where a riser angle monitoring transponder is fitted to the riser and a remote inclinometer unit is installed on the Blow Out Preventer (BOP) and interrogated through the ship’s HPR.
- Light taut wire, LTW or LWTW. The oldest position reference system used for DP is still very accurate in relatively shallow water. A clumpweight is lowered to the seabed. By measuring the amount of wire paid out and the angle of the wire by a gimbal head, the relative position can be calculated. Care should be taken not to let the wire angle become too large to avoid dragging. For deeper water the system is less favourable, as current will curve the wire. There are however systems that counteract this with a gimbal head on the clumpweight. Horizontal LTW’s are also used when operating close to a structure. Objects falling on the wire are a risk here.
- Fanbeam and CyScan. These are laser based position reference systems. They are very straightforward system, as only a small prism needs to be installed on a nearby structure or ship. Risks are the system locking on other reflecting objects and blocking of the signal. Range depends on the weather, but is typically more than 500 meters.[6]
- Artemis. A radar-based system. A unit is placed on a nearby structure and aimed at the unit on board the ship. The range is several kilometres. Advantage is the reliable, all-weather performance. Disadvantage is that the unit is rather heavy.[7]
- DARPS, Differential, Absolute and Relative Positioning System. Commonly used on shuttle tankers while loading from a FPSO. Both will have a GPS receiver. As the errors are the same for the both of them, the signal does not need to be corrected. The position from the FPSO is transmitted to the shuttle tanker, so a range and bearing can be calculated and fed into the DP system.
- RADius[8] and RadaScan. These are radar based system, but have no moving parts as Artemis. Another advantage is that the transponders are much smaller than the Artemis unit. The range is typically 500 – 1000 meters.
- Inertial navigation is used in combination with any of the above reference systems, but typically with gnss (Global Navigation Satellite System) and Hydroacoustics (USBL, LBL, or SBL).
Heading reference systems
- Gyrocompasses are normally used to determine heading.
More advanced methods are:
- Ring-Laser gyroscopes
- Fibre optic gyroscopes
- Seapath, a combination of GPS and inertial sensors.
Sensors
Besides position and heading, other variables are fed into the DP system through sensors:
- Motion reference units, vertical reference units or vertical reference sensors, VRUs or MRUs or VRSs, determine the ship's roll, pitch and heave.
- Wind sensors are fed into the DP system feedforward, so the system can anticipate wind gusts before the ship is blown off position.
- Draught sensors, since a change of draught influences the effect of wind and current on the hull.
- Other sensors depend on the kind of ship. A pipelay ship may measure the force needed to pull on the pipe, large crane vessels will have sensors to determine the cranes position, as this changes the wind model, enabling the calculation of a more accurate model (see Control systems).
Control systems
In the beginning PID controllers were used and today are still used in the simpler DP systems. But modern controllers use a mathematical model of the ship that is based on a hydrodynamic and aerodynamic description concerning some of the ship's characteristics such as mass and drag. Of course, this model is not entirely correct. The ship's position and heading are fed into the system and compared with the prediction made by the model. This difference is used to update the model by using Kalman filtering technique. For this reason, the model also has input from the wind sensors and feedback from the thrusters. This method even allows not having input from any PRS for some time, depending on the quality of the model and the weather. This process is known as dead reckoning.
The accuracy and precision of the different PRSs is not the same. While a DGPS has a high accuracy and precision, a USBL can have a much lower precision. For this reason, the PRS’s are weighted. Based on variance a PRS receives a weight between 0 and 1.
Power and propulsion systems[edit]
To maintain position azimuth thrusters (electric, L-drive or Z-drive) bow thrusters, stern thrusters, water jets, ruddersand propellers are used. DP ships are usually at least partially diesel-electric, as this allows a more flexible set-up and is better able to handle the large changes in power demand, typical for DP operations.
The set-up depends on the DP class of the ship. A Class 1 can be relatively simple, whereas the system of a Class 3 ship is quite complex.
On Class 2 and 3 ships, all computers and reference systems should be powered through a UPS.
Class requirements
Based on IMO (International Maritime Organization) publication 645[9] the Classification Societies have issued rules for Dynamic Positioned Ships described as Class 1, Class 2 and Class 3.
- Equipment Class 1 has no redundancy.
Loss of position may occur in the event of a single fault.
- Equipment Class 2 has redundancy so that no single fault in an active system will cause the system to fail.
Loss of position should not occur from a single fault of an active component or system such as generators, thruster, switchboards, remote controlled valves etc., but may occur after failure of a static component such as cables, pipes, manual valves etc.
- Equipment Class 3 which also has to withstand fire or flood in any one compartment without the system failing.
Loss of position should not occur from any single failure including a completely burnt fire sub division or flooded watertight compartment.
Classification Societies have their own Class notations:
| Description | IMO Equipment Class | LR Equipment Class | DNV Equipment Class | GL Equipment Class | ABS Equipment Class | NK Equipment Class | BV Equipment Class |
| Manual position control and automatic heading control under specified maximum environmental conditions | - | DP(CM) | DYNPOS-AUTS | - | DPS-0 | - | |
| Automatic and manual position and heading control under specified maximum environmental conditions | Class 1 | DP(AM) | DYNPOS-AUT & DPS1 | DP 1 | DPS-1 | DPS A | DYNAPOS AM/AT |
| Automatic and manual position and heading control under specified maximum environmental conditions, during and following any single fault excluding loss of a compartment. (Two independent computer systems). | Class 2 | DP(AA) | DYNPOS-AUTR & DPS2 | DP 2 | DPS-2 | DPS B | DYNAPOS AM/AT R |
| Automatic and manual position and heading control under specified maximum environmental conditions, during and following any single fault including loss of a compartment due to fire or flood. (At least two independent computer systems with a separate backup system separated by A60 class division). | Class 3 | DP(AAA) | DYNPOS-AUTRO & DPS3 | DP 3 | DPS-3 | DPS C | DYNAPOS AM/AT RS |
DNV rules 2011 Pt6 Ch7 introduced "DPS" series of classification to compete with ABS "DPS" series.
NMA
Where IMO leaves the decision of which class applies to what kind of operation to the operator of the DP ship and its client, the Norwegian Maritime Authority(NMA) has specified what Class should be used in regard to the risk of an operation. In the NMA Guidelines and Notes No. 28, enclosure A four classes are defined:
- Class 0 Operations where loss of position keeping capability is not considered to endanger human lives, or cause damage.
- Class 1 Operations where loss of position keeping capability may cause damage or pollution of small consequence.
- Class 2 Operations where loss of position keeping capability may cause personnel injury, pollution, or damage with large economic consequences.
- Class 3 Operations where loss of position keeping capability may cause fatal accidents, or severe pollution or damage with major economic consequences.
Based on this the type of ship is specified for each operation:
- Class 1 DP units with equipment class 1 should be used during operations where loss of position is not considered to endanger human lives, cause significant damage or cause more than minimal pollution.
- Class 2 DP units with equipment class 2 should be used during operations where loss of position could cause personnel injury, pollution or damage with great economic consequences.
- Class 3 DP units with equipment class 3 should be used during operations where loss of position could cause fatal accidents, severe pollution or damage with major economic consequences.
Redundancy
Redundancy is the ability to withstand, while on DP mode, the loss of equipment which is online, without losing position and/or heading. A single failure can be, amongst others:
- Thruster failure
- Generator failure
- Powerbus failure (when generators are combined on one powerbus)
- Control computer failure
- Position reference system failure
- Reference system failure
For certain operations redundancy is not required. For instance, if a survey ship loses its DP capability, there is normally no risk of damage or injuries. These operations will normally be done in Class 1.
For other operations, such as diving and heavy lifting, there is a risk of damage or injuries. Depending on the risk, the operation is done in Class 2 or 3. This means at least three Position reference systems should be selected. This allows the principle of voting logic, so the failing PRS can be found. For this reason, there are also three DP control computers, three gyrocompasses, three MRU’s and three wind sensors on Class 3 ships. If a single fault occurs that jeopardizes the redundancy, i.e., failing of a thruster, generator or a PRS, and this cannot be resolved immediately, the operation should be abandoned as quickly as possible.
To have sufficient redundancy, enough generators and thrusters should be on-line so the failure of one does not result in a loss of position. This is left to the judgment of the DP operator. For Class 2 and Class 3 a Consequence Analysis should be incorporated in the system to assist the DPO in this process.
Disadvantage is that a generator can never operate at full load, resulting in less economy and fouling of the engines. To avoid the engines to work under low loads, there's an allocation mode to the thrusters called "biasing", in which the thrusters are set in pairs counteracting each other, with a precise control of such counteraction, in order to adjust the generators/engines working load. When an engine works under a low load for some time it accumulates carbon deposits on the upper part of the cylinder, which can damage the pistons and all other moving equipment related to the piston movement.
The redundancy of a DP ship should be judged by a failure mode and effects analysis (FMEA) study and proved by FMEA trials.[10] Besides that, annual trials are done and normally DP function tests are completed prior to each project.
